EBOX V3 60 Black
EBOX V3 60 Black
 1,799.00

[wpforms id=”1190″ title=”true” description=”Request a call back”]

EBOX V3 has finally arrived! You wanted more power, more punch, more range, more control and a higher top speed?? We listened to you, and we delivered all of that and more, featuring the brand new EBX powertrain! Bigger batteries, a Fardriver 80A controller and a high power PMSM motor with encoder and temperature feedback with up to 6.3kW. There are no hall sensors to fail and the precise control of the encoder, provides laser sharp coil firing for increased efficiency and maximum performance. Added to that we have included a colour TFT display with 3-speed modes and fault-finding capability. Our warranty has been increased to 1 year, (or 1000 miles) on all powertrain components (battery, controller, motor). What does this mean? Basically, peaking top speeds of up to 55 mph! New colourways, new tyres and all in the same mini package you can throw in the trunk of your car. .

SPECS

Frame typeV3 Double Cradle
Front wheel size14″
Rear wheel size12″
Fork150mm travel USD
Rear SuspensionProgressive mono shock 150mm travel
Bar RisersAlloy Cast 36mm rise Ø22.2
Front brakeHyraulic Disc (Right lever) e-moto brakes
Front disc180mm rotor, 4 bolt
Rear brakeHyraulic Disc (Left lever) e-moto brakes
Rear disc180mm rotor, 4 bolt
Front tyre60/100-14 Dirt
Rear tyre80/100-12 Dirt
Chain219H 120L
GearingFront 10T, Rear 70T
Max load85kg
Handlebar6061 T6 EBOX High Rise 1pc
SeatEBOX fat seat
Motor60V EBX PMSM motor with temp feedback and encoder
Rated Power3.3KW
Peak power3.7KW (5hp)
Max RPM7,500
Battery60v 18.2Ah battery 18,600 cells with QS8 connector and air breaker switch
Controller80 Amp fardriver controller
ThrottleSURRON style full twist
DisplayTFT odometer display with 3 speed modes and fault code analysis software
ConnectorsAutomotive connectors with sealed wiring harness
ChargerAC 100-240V, Output: 67.2V, 3A

TECH

Charge time5-6 hours
Range21-25 miles (35-40Km)
Top speed45mph (72Km/h)
External adjustability3 riding modes
Frame constructionV3 wide frame (183mm), race inspired revised geometry. Increased fork travel, increased pre-load and heavier oil. Standard Footpeg.
Wheelbase980mm
Seat height650mm
Bike Weight46.2kg (101lbs)
WarrantyEBX 1 year/1000 miles (whichever comes first) powertrain warranty. 6 month parts warranty. See T&C’s for more information
